Make a robotics project someone else can reproduce
Record model versions, setup steps, test cases and limitations in a useful robotics project README.
A short demo shows an outcome. A useful project record explains how that outcome was produced. Begin with the purpose of the experiment and one measurable requirement. State whether the project was tested on physical hardware, simulated in software or remains a proposal. Those are different kinds of evidence.
List the exact model and hardware revision, firmware or code version, coding environment and additional parts. Link to the relevant upstream instructions instead of copying wiring for a different board. CYOBot v2 and the original CYOCrawler have separate repositories; identify which one your experiment uses.
Write a minimal setup sequence that starts from a known working example. Include the expected first visible result and how to restore that baseline. When an experiment fails, record the input, expected result, actual result and the single change you tried next. A reproducible failure is useful evidence too.
Add a small test table. For a distance decision, include missing readings and values on both sides of the threshold. For a display or game, include boundary positions, timing and restart behaviour. Note which tests run without a robot and which depend on physical conditions. Avoid presenting one successful run as evidence for every operating condition.
Publish only material you own or have permission to share. Check upstream licences and credit sources. Remove passwords, WiFi credentials, access tokens and private learner information. Use your own photographs or approved assets, and describe limitations rather than promising that another person's hardware will behave identically.
Try it step by step
- State the requirement and the kind of evidence you have.
- Record model, firmware, dependencies and setup.
- Keep a test table with expected and actual results.
- Check permissions, licences and secrets before publishing.
